1. redis事件的定义

/* State of an event based program */typedef struct aeEventLoop {    int maxfd;   /* highest file descriptor currently registered */    int setsize; /* max number of file descriptors tracked */    long long timeEventNextId; /*下一个定时器的id*/    time_t lastTime;     /* Used to detect system clock skew */    aeFileEvent *events; /* Registered events注册的文件事件  */    aeFiredEvent *fired; /* Fired events 已注销的文件事件 */    aeTimeEvent *timeEventHead;  /*定时器事件链表的首部*/     int stop;     void *apidata; /* This is used for polling API specific data */

aeBeforeSleepProc *beforesleep;     } aeEventLoop;

  1.1 事件定义

/* File event structure */

typedef struct aeFileEvent {

int mask; /* one of AE_(READABLE|WRITABLE) */

aeFileProc *rfileProc;

aeFileProc *wfileProc;

void *clientData;

} aeFileEvent;

/* Time event structure */

typedef struct aeTimeEvent {

long long id; /* time event identifier. */

long when_sec; /* seconds */

long when_ms; /* milliseconds */

aeTimeProc *timeProc;

aeEventFinalizerProc *finalizerProc;

void *clientData;

struct aeTimeEvent *next;

} aeTimeEvent;

/* A fired event */

typedef struct aeFiredEvent {

int fd;

int mask;

} aeFiredEvent;

2.封装事件处理的实现

/* Include the best multiplexing layer supported by this system. * The following should be ordered by performances, descending. */#ifdef HAVE_EVPORT#include "ae_evport.c"#else    #ifdef HAVE_EPOLL    #include "ae_epoll.c"    #else        #ifdef HAVE_KQUEUE        #include "ae_kqueue.c"        #else        #include "ae_select.c"        #endif    #endif#endif

 3.事件处理的主函数

void aeMain(aeEventLoop *eventLoop) {    eventLoop->stop = 0;    while (!eventLoop->stop) {        if (eventLoop->beforesleep != NULL)            eventLoop->beforesleep(eventLoop);        aeProcessEvents(eventLoop, AE_ALL_EVENTS);    }}

  3.1事件处理过程

/* Process every pending time event, then every pending file event * (that may be registered by time event callbacks just processed). * Without special flags the function sleeps until some file event * fires, or when the next time event occurs (if any). * * If flags is 0, the function does nothing and returns. * if flags has AE_ALL_EVENTS set, all the kind of events are processed. * if flags has AE_FILE_EVENTS set, file events are processed. * if flags has AE_TIME_EVENTS set, time events are processed. * if flags has AE_DONT_WAIT set the function returns ASAP until all * the events that's possible to process without to wait are processed. * * The function returns the number of events processed. */int aeProcessEvents(aeEventLoop *eventLoop, int flags){    int processed = 0, numevents;    /* Nothing to do? return ASAP */    if (!(flags & AE_TIME_EVENTS) && !(flags & AE_FILE_EVENTS)) return 0;    /* Note that we want call select() even if there are no     * file events to process as long as we want to process time     * events, in order to sleep until the next time event is ready     * to fire. */    if (eventLoop->maxfd != -1 ||        ((flags & AE_TIME_EVENTS) && !(flags & AE_DONT_WAIT))) {        int j;        aeTimeEvent *shortest = NULL;        struct timeval tv, *tvp;        if (flags & AE_TIME_EVENTS && !(flags & AE_DONT_WAIT))            shortest = aeSearchNearestTimer(eventLoop);        if (shortest) {            long now_sec, now_ms;            /* Calculate the time missing for the nearest             * timer to fire. */            aeGetTime(&now_sec, &now_ms);            tvp = &tv;            tvp->tv_sec = shortest->when_sec - now_sec;            if (shortest->when_ms < now_ms) {                tvp->tv_usec = ((shortest->when_ms+1000) - now_ms)*1000;                tvp->tv_sec --;            } else {                tvp->tv_usec = (shortest->when_ms - now_ms)*1000;            }            if (tvp->tv_sec < 0) tvp->tv_sec = 0;            if (tvp->tv_usec < 0) tvp->tv_usec = 0;        } else {            /* If we have to check for events but need to return             * ASAP because of AE_DONT_WAIT we need to set the timeout             * to zero */            if (flags & AE_DONT_WAIT) {                tv.tv_sec = tv.tv_usec = 0;                tvp = &tv;            } else {                /* Otherwise we can block */                tvp = NULL; /* wait forever */            }        }        numevents = aeApiPoll(eventLoop, tvp);        for (j = 0; j < numevents; j++) {            aeFileEvent *fe = &eventLoop->events[eventLoop->fired[j].fd];            int mask = eventLoop->fired[j].mask;            int fd = eventLoop->fired[j].fd;            int rfired = 0;        /* note the fe->mask & mask & ... code: maybe an already processed             * event removed an element that fired and we still didn't             * processed, so we check if the event is still valid. */            if (fe->mask & mask & AE_READABLE) {                rfired = 1;                fe->rfileProc(eventLoop,fd,fe->clientData,mask);            }            if (fe->mask & mask & AE_WRITABLE) {                if (!rfired || fe->wfileProc != fe->rfileProc)                    fe->wfileProc(eventLoop,fd,fe->clientData,mask);            }            processed++;        }    }    /* Check time events */    if (flags & AE_TIME_EVENTS)        processed += processTimeEvents(eventLoop);    return processed; /* return the number of processed file/time events */}

/* Process time events */static int processTimeEvents(aeEventLoop *eventLoop) {    int processed = 0;    aeTimeEvent *te;    long long maxId;    time_t now = time(NULL);    /* If the system clock is moved to the future, and then set back to the     * right value, time events may be delayed in a random way. Often this     * means that scheduled operations will not be performed soon enough.     *     * Here we try to detect system clock skews, and force all the time     * events to be processed ASAP when this happens: the idea is that     * processing events earlier is less dangerous than delaying them     * indefinitely, and practice suggests it is. */    if (now < eventLoop->lastTime) {        te = eventLoop->timeEventHead;        while(te) {            te->when_sec = 0;            te = te->next;        }    }    eventLoop->lastTime = now;    te = eventLoop->timeEventHead;    maxId = eventLoop->timeEventNextId-1;    while(te) {        long now_sec, now_ms;        long long id;        if (te->id > maxId) {            te = te->next;            continue;        }        aeGetTime(&now_sec, &now_ms);        if (now_sec > te->when_sec ||            (now_sec == te->when_sec && now_ms >= te->when_ms))        {            int retval;            id = te->id;            retval = te->timeProc(eventLoop, id, te->clientData);            processed++;            /* After an event is processed our time event list may             * no longer be the same, so we restart from head.             * Still we make sure to don't process events registered             * by event handlers itself in order to don't loop forever.             * To do so we saved the max ID we want to handle.             *             * FUTURE OPTIMIZATIONS:             * Note that this is NOT great algorithmically. Redis uses             * a single time event so it's not a problem but the right             * way to do this is to add the new elements on head, and             * to flag deleted elements in a special way for later             * deletion (putting references to the nodes to delete into             * another linked list). */            if (retval != AE_NOMORE) {                aeAddMillisecondsToNow(retval,&te->when_sec,&te->when_ms);            } else {                aeDeleteTimeEvent(eventLoop, id);            }            te = eventLoop->timeEventHead;        } else {            te = te->next;        }    }    return processed;}
